SynapseCore
The first hybrid building controller (HBC) that combines the power of industrial building management systems with the agility of an IoT gateway.
Designed for BACS compliance and energy performance, it centralizes the management of your building. Collect data (LoRaWAN, wired), execute resilient local scenarios, and supervise everything via EwattchCloud.
Plug & Play: Lightning-fast deployment with Scan-to-Cloud.
Universal: native interoperability (Modbus, BACnet, KNX, MQTT).
Robust: secure stand-alone operation, even offline.
The benefits
Why choose SynapseCore?
SynapseCore (HBC) solves the age-old dilemma between heavy, expensive BMS systems and lightweight IoT solutions. It offers the best of both worlds for building control, predictive maintenance, energy management and regulatory compliance.
Ideal for existing buildings (retrofit without work)
Modernize existing buildings without breaking down walls or laying kilometers of cable. Thanks to its private LoRaWAN network and its ability to be grafted onto existing equipment, SynapseCore can make an old building (hotel, office, warehouse...) intelligent at a fraction of the cost of a traditional BMS.
Total Interoperability
Don't choose between wired and radio. SynapseCore integrates a private LoRaWAN hub (embedded LNS) for your IoT sensors, and speaks building languages natively (Modbus-TCP/RTU, BACnet, KNX, DALI). It unifies your existing infrastructure.
Unified Architecture: Fusion BMS + IoT
That's SynapseCore's #1 strength. It doesn't force you to choose. It combines the power of a wired BMS (to control large HVAC equipment) with the agility ofLoRaWAN IoT (to deploy wireless sensors everywhere). It's the perfect bridge between your old installations and tomorrow's intelligent building.
BACS & Tertiary Decree compliance
SynapseCore is the technical tool you need to meet regulatory targets. From simple monitoring to automated control, it enables you to classify your BMS as Class A or B, and generate the energy savings required by the French government.
Continuity
of Service
Internet connection down? Your building keeps running. Thanks to its on-board intelligence (Edge Computing), SynapseCore runs critical scenarios locally. As soon as the network returns, it synchronizes secure data with EwattchCloud.
Expert Support & Scan-to-Cloud
Save time with Scan-to-Cloud auto-configuration, but above all secure your projects with our Integration Support Service. When faced with complex protocols or technical challenges, our experts will train you and intervene directly at your side to guarantee successful deployment. More than a product, you benefit from a genuine technical partnership.
Features
The power of a BMS, plus simplicity
A complete ecosystem to connect, automate and secure your buildings. We have integrated gas pedal tools, such as our model library, to enable our partners to deploy complex systems in record time.
Scenario Library
Save precious time on your building sites. SynapseCore comes with a library of pre-programmed scenarios (class A or B hotel room control, heating control, lighting schedules, AHU control and analysis, etc.). Select the scenario best suited to your needs, configure and duplicate it, and the system is ready to go. There's no need to start from scratch, and no need for strong programming skills.
Private LoRaWAN network
Create your own IoT network without relying on a third-party operator. The integrated hub manages your wireless sensors locally, decodes frames and guarantees Deep Indoor coverage throughout the building.
Multiprotocol interoperability
Break down technological silos. SynapseCore dialogs natively with market standards: Modbus TCP/RTU, BACnet/IP, KNX, DALI and MQTT. It centralizes data from your meters, central air handling units (AHUs) and electrical panels on a single interface.
Unified HVAC control
Control the biggest consumption items. SynapseCore interfaces directly with all HVAC systems : VRV/VRF, fan coil units, PAC, CTA, electric and hot water radiators... It enables fine management of temperature setpoints, zone by zone, for BACS compliance.
-
Features
Features SynapseCore
Reference
SYNAPSECORE-HBC10
Processor / RAM
ARM Cortex Quad-Core / 4 GB DDR4 RAM
Storage
eMMC 16 GB (Expandable via microSD / M.2)
Embedded OS
Linux Ewattch optimized & secured.
LoRaWAN Wireless Network
Integrated LoRaWAN™ hub (embedded LNS). Native AES-128 encryption.
Radio
Wi-Fi/Bluetooth connectivity
Ethernet ports
Double Gigabit LAN: 2 isolated Ethernet ports (RJ45) to separate the OT network (equipment) from the IT network (Internet).
Supported protocols
Modbus RTU/TCP, BACnet, KNX, MQTT...
Power supply
Power over Ethernet (PoE) or
12V - 24V DC compatible terminal block
Case
15 × 15 × 5 cm
Mounting
DIN rail or supplied in wall-mounted box
Resistance
Operational from -30°C to +70°C.
Certifications
CE, RED, RoHS. Compatible with standardized KNX and LoRaWAN protocols.
Support
Access to EwattchBuilder for advanced customization and technical training available for certified partners.
